Product Description:
- Our level 2 EV charger charges your electric vehicle 8 times faster than a standard level 1 charger.
- It provides up to 36 miles of range per hour of charge, with a maximum output of 9.6 kW/40A.
- The charger supports flexible amperage settings based on your car model.
- You can schedule the charging start time to take advantage of lower electricity prices during off-peak hours.
- The charger comes with a 16.4ft cable, suitable for most patios or garages.
- Its portable design allows for easy transportation and charging anywhere you go.
- The OLED screen and 360° ring light provide quick charging status updates.
- It is safe, efficient, and reliable, with IP65 dust and water resistance certification.
- The charger features leakage, overvoltage, overheating, and overcurrent protection.
- You can confidently charge your vehicle with our high-quality and reliable EV charger.
Features:
- Product Name: Portable Electric Car Chargers
- Output Current: 8A-40A
- Function: Fast Charging
- RCD: Type A OR Type A+6mA D.c.
- Certification: CE, FCC, RoHS
- Relative humidity : 5%RH~95%RH
- Portable 220v EV Charger
- ev charger cable
- 8X FasterCharging
- Portable
- Timer Function
- OLED Screen
- Multi Protection
- Adjustable Current
- IP65 In/Outdoor Use
Technical Parameters:
| Phase | Single Phase | Three Phase |
| Input/output voltage | 110~250Va.c. | 110~450Va.c. |
| Frequency | 50Hz/60Hz | 50Hz/60Hz |
| Max.current | 16A/32A | 16A/32A |
| EV connector | Type 1& Type 2 | Type 2 |
| RCD | Type A | Type A+6mA d.c. |
| IP degree | IP65 | IP65 |
| Operating temperature | -25~+50 | -25~+50 |
| Relative humidity | 5%RH~95%RH | 5%RH~95%RH |
| Altitude | <2000m | <2000m |
| Static power | <2W | <2W |
| Dimension | 278mm(L)*81mm(D) | 278mm(L)*81mm(D) |
| Standards | IEC/EN 62752 | IEC/EN 62752 |
| Certification | CE | CE |
Applications:
The level 2 electric vehicle charger is compatible with all-electric and plug-in hybrid vehicles that meet J1772 standards. Popular models like Chevrolet Bolt EV/EUV, BMW 5 Series 530e, Ford C-Max Energi, Hyundai Ioniq Electric, etc. Tesla also requires a J1772 adapter(not included)
FAQ:
Q: What are the advantages of European standard car chargers?
A: European standard car chargers comply with European charging standards and regulations. They have a high degree of safety and charging efficiency.
Q: Is the European standard car charger compatible with my electric car?
A: Most European standard car chargers are compatible with electric vehicles that comply with European standards. Make sure your electric car complies with European standards and supports the corresponding charging interface.
Q: How to choose a European standard car charger suitable for me?
A: First, understand the charging needs and charging interface types of your electric vehicle.
Then, choose a European standard charger that is compatible with your electric car.
You can refer to the vehicle manufacturer's recommendations or consult a professional for the correct charger selection.
Picture:
(HOW TO USE THE EV PORTABLE CAR CHARGER)
one:
Insert the wallside plug to theelectrical outlet
two:
Press the APMS button to set the charging current
three:
Press theTIME buttonto set the delary time
four :
Plug the EV connector into the socket
five:
Pls confrm the device is under nomial warking status: the ring light is flashing.
